INTERIOR TRIM COMPONENTS

76-3-6

REPAIRS

Trim finisher - 'B/C' post - upper - renew

$% 76.13.28

Remove

1. Remove seat base finisher.

 +

 SEATS, REPAIRS, Finisher - seat

base - front - each.

2. Remove Torx bolt securing rear seat belt lower

fixing to body and position seat belt aside.

3. Release finisher from 6 retaining clips and

remove finisher.

NOTE: Do not carry out further dismantling if
component is removed for access only.

4. Remove 6 retaining clips from finisher.
5. Remove seat belt slide.

Refit

1. Fit seat belt slide to finisher.
2. Fit retaining clips to finisher.
3. Position finisher and engage retaining clips.
4. Position seat belt lower mounting, fit Torx bolt

and tighten to 40 Nm (29 lbf.ft).

5. Fit seat base finisher.

 +

 SEATS, REPAIRS, Finisher - seat

base - front - each.
