Automatic gearboxRemove · page 2 of 3
Exploded view diagram of automatic gearbox components with lettered callouts A through Z and AA
  1. A Torque converter
  2. B Oil pump assembly
  3. C Pump drive plate
  4. D O-ring seal
  5. E Pressure relief valve assembly
  6. F Valve body cover
  7. G Valve body gasket
  8. H Valve body
  9. I Valve body gasket
  10. J Control lever
  11. K Manual valve assembly
  12. L Fastener
  13. M Manual shift valve assembly
  14. N Gearbox casing
  15. O Front clutch assembly
  16. P Clutch pack plate
  17. Q Solenoid valve
  18. R Fastener
  19. S Solenoid valve
  20. T Solenoid valve connector
  21. U Speedometer drive gear
  22. V Output shaft assembly
  23. W Bush
  24. X Gasket
  25. Y Valve body cover
  26. Z Fastener
  27. AA Rear band assembly
  28. BB Band strut
  29. CC Fastener
  30. DD Valve body gasket
  31. EE Fastener
  32. FF Check ball
  33. GG Fastener
  34. HH Accumulator piston assembly
