Range Rover P38
76
CHASSIS AND BODY
NEW RANGE ROVER
2
REPAIR
BONNET LOCK PIN
Service repair no - 76.16.24
Remove
1. Remove bolts securing lock pin to bonnet.
2. Remove pin.
Refit
3. Position lock pin to bonnet.
4. Fit bolts but do not tighten.
5. Close and open bonnet to align pin.
6. Secure pin with bolts.
7. Lubricate pin.
BONNET LOCK - LEFT HAND
Service repair no - 76.16.21
Remove
1. Remove bolts securing bonnet lock.
2. Release outer and inner cables from lock.
3. Remove lock.
Refit
4. Reverse removal procedure.
