CHASSIS AND BODY
67
REPAIR
HEADLINING - SLIDING ROOF
Service repair no - 76.64.15
Remove
1. Remove upper trims from ’A’,’B’,’D’ & ’E’ posts.
See this section.
2. Remove both sun visors.
See this section.
3. Remove grab handles.
See this section.
4. Remove parcel tray support trim.
See this
section.
5. Remove interior lamps.
See ELECTRICAL,
Repair.
6. Remove front courtesy lamp.
See
ELECTRICAL, Repair.
7. Remove ultrasonic sensor.
See ELECTRICAL,
Repair.
8. Fold down rear seat squabs. Recline front seat
squabs.
9. Release aperture sealing rubbers at tops of
doors and tailgate.
10. Release sun visor clip retaining screw cover
plugs.
11. Remove sun visor retaining clip screws. Remove
clips.
12. Remove sun roof aperture finisher.
13. Remove 2 headlining grab handle blanks.
14. Remove 2 studs securing rear of headlining.
15. With assistance remove headlining.
Refit
16. Reverse removal procedure.
