Range Rover P38
CHASSIS AND BODY
59
REPAIR
FRONT SEAT BELT ADJUSTABLE MOUNTING
Service repair no - 76.73.26
Remove
1. Remove ’B’ post trim upper.
2. Remove 2 screws securing adjustable mounting.
Remove mounting.
Refit
3. Position adjustable mounting. Secure with
screws. Tighten to
25 Nm. (18 lbf.ft)
4. Fit ’B’ post trim upper.
SEAT BELT ADJUSTABLE MOUNTING - ’D’ POST
Service repair no - 76.73.36
Remove
1. Remove ’D’ post trim - upper.
2. Remove 2 screws securing adjustable mounting.
Remove mounting.
Refit
3. Position adjustable mounting. Secure with
screws. Tighten to
25 Nm. (18 lbf.ft)
4. Refit ’D’ post trim - upper.
