Range Rover P38
76
CHASSIS AND BODY
NEW RANGE ROVER
40
REPAIR
Refit
7. Clean handle face on door.
8. Fit handle mounting plate, tighten screw.
9. Fit locking plates.
10. Fit gasket to handle, position handle, secure with
screw.
11. Refit door trim casing.
See this section.
LATCH - REAR DOOR
Service repair no - 76.37.13/70
Remove
1. Remove window lift motor/control unit assembly.
See ELECTRICAL, Repair.
2. Release door lock remote control cable from clip
on window lift panel.
3. Remove 2 studs securing latch to window lift
panel.
4. Disconnect outer cable from abutment bracket.
5. Release remote cable from latch.
6. Release sill button link rod from latch. Remove
latch.
Refit
7. Lubricate new latch.
8. Fit latch to sill button link rod.
9. Fit remote control cable to latch.
10. Fit latch to window lift panel, secure with 2
retaining studs.
11. Refit window lift motor/control unit assembly.
See ELECTRICAL, Repair.
