Range Rover P38
76
CHASSIS AND BODY
NEW RANGE ROVER
48
REPAIR
4. Remove 2 screws securing lock and withdraw
cable assembly from fascia.
5. Pry cover from lock button.
6. Insert key into lock, turn key through 45 degrees,
remove barrel.
Refit
7. Insert barrel, turn to engage in button.
8. Remove key, fit cover to lock button.
9. Route release cable assembly into fascia.
Engage cable latch to glove box.
10. Align glove box liner to fascia, tighten screws.
11. Close glove box lid.
12. Position glove box lock to fascia, check
operation of latch.
13. If adjustment is necessary, release lock from
fascia, loosen cable lock nut, adjust outer cable
length. Tighten cable lock nut.
14. Reposition lock to fascia. Recheck operation of
latch before securing lock with screws.
15. Fit finisher to lock.
GRAB HANDLE
Service repair no - 76.58.30
Remove
1. Pull down grab handle.
2. Remove 2 grab handle retaining screw access
covers.
3. Remove 2 screws, remove grab handle.
Refit
4. Position grab handle, fit 2 retaining screws.
5. Fit 2 retaining screw access covers.
6. Release grab handle.
