Range Rover P38
CHASSIS AND BODY
27
REPAIR
Refit
8. Passenger side: Fit glove box lock bezel.
9. Fit fixing stud inserts to fascia.
10. Fit veneered panel to fascia.
11. Close glove box.
12. Drivers side: Fit fixing stud inserts to fascia.
13. Fit veneered panel to fascia.
14. Drivers side: Fit fascia closing panel.
See this
section.
PANEL - FASCIA CLOSING
Service repair no - 76.46.28
Remove
1. Release steering column adjustment lock, raise
and extend column for access to panel upper
screws.
2. Remove 4 screw covers from fascia closing
panel and remove screws.
3. Remove 2 screws securing top of closing panel.
4. Disconnect air tube and remove closing panel.
Refit
5. Position closing panel and connect air tube.
6. Fit closing panel to fascia and secure with
screws.
7. Fit screw covers and reposition steering column.
