Range Rover P38 Tailgate Latch Repair - Outer Fix
CHASSIS AND BODY
77
REPAIR
TAILGATE LATCH
Service repair no - 76.37.17
Remove
1. Release studs securing tailgate board. Remove
board.
2. Release clips securing operating rods to tailgate
centre latch. Release rods.
3. Disconnect latch multiplug.
4. Remove 2 bolts securing latch to tailgate.
Remove latch.
Refit
5. Reverse removal procedure.
TAILGATE LATCH - OUTER
Service repair no - 76.37.73
Remove
1. Release studs securing tailgate board. Remove
board.
2. Release clip securing outer latch rod. Disconnect
rod from centre latch.
