Range Rover P38
76
CHASSIS AND BODY
NEW RANGE ROVER
42
REPAIR
GLASS CHANNEL - REAR DOOR
Service repair no - 76.31.17
Remove
1. Remove window lift motor/control panel
assembly.
See ELECTRICAL, Repair.
2. Remove 2 bolts securing channel to door and
remove channel.
Refit
3. Fit channel to door, secure with 2 bolts.
4. Refit window lift motor/control panel assembly.
See ELECTRICAL, Repair.
SEAL - REAR DOOR
Service repair no - 76.40.02
Remove
1. Open rear door.
2. Remove rear door carpet retainer.
3. Remove rear door aperture seal.
Refit
4. Fit rear door aperture seal.
5. Refit rear door carpet retainer.
6. Close rear door.
