Range Rover P38
CHASSIS AND BODY
29
REPAIR
6. Remove front lower fixing clip.
7. Remove nut securing bracket to vertical slide.
8. Release bracket from slide.
CAUTION: Chock glass with wooden
block, or retain with tape, to prevent glass
dropping when regulator arms are
released.
9. Using a suitable lever, release 2 regulator arms
from glass lower fixings.
10. Support weight of glass. Remove wooden chock
or tape.
11. Rotate glass anti-clockwise to release from
runners.
12. Remove front door glass.
Refit
13. Refit front door glass.
14. Rotate glass anti-clockwise, fit to runners.
15. Secure glass fixings to regulator arms.
16. Position glass bracket to vertical runner, fit
retaining nut.
17. Fit clip securing regulator arm to glass runner.
18. Turn ignition ON.
19. Raise door glass approximately 120mm (5 in.)
Fit rear glass retaining clip.
20. Raise door glass.
21. Turn ignition OFF.
22. Fit front door plastic sheet.
See this section.
23. Fit front door outer waist seal.
See this section.
