Switch - inertia

FUEL DELIVERY SYSTEM - PETROL

REPAIRS 19-2-11

Switch - inertia

$% 19.22.09

Remove

1. Disconnect multiplug from fuel cut-off switch.
2. Remove bolt securing fuel cut-off switch

bracket to bulkhead.

3. Remove fuel cut-off switch from bulkhead.
4. Remove 2 nuts securing fuel cut-off switch to

bracket.

5. Remove fuel cut-off switch from bracket.

Refit

1. Position fuel cut-off switch to bracket.
2. Fit nuts securing fuel cut-off switch to bracket

and tighten to 2 Nm (1.5 lbf.ft).

3. Position fuel cut-off switch bracket to bulkhead.
4. Fit and tighten bolt securing fuel cut-off switch

bracket to bulkhead.

5. Connect multiplug to fuel cut-off switch.
6. To set the fuel cut-off switch, depress the top of

the fuel cut-off switch.
