Freelander Service Procedures
RESTRAINT SYSTEMS
75-8
REPAIRS
Pre-tensioner - seat belt - front
$% 76.73.75
Remove
WARNING: It is imperative that before any
work is undertaken on the SRS system the
appropriate information is read thoroughly.
WARNING: When removing, testing or
installing a seatbelt pre-tensioner, do not
lean directly over it or block the end of the
piston tube.
1. Make the SRS system safe.
Supplementary restraint system
precautions.
2. Remove rear console.
3. Disconnect pretensioner multiplug.
4. Remove Torx bolt securing pretensioner to seat
and remove pretensioner.
WARNING: Store the airbag module or seat
belt pre-tensioner in a designated storage
area. If there is no designated storage area
available, store in the locked luggage
compartment/loadspace of the vehicle and
inform the workshop supervisor.
Refit
NOTE: If the SRS component is to be replaced,
the bar code of the new unit must be recorded.
1. Position pretensioner to seat and tighten Torx
bolt to 32 Nm (24 lbf.ft).
2. Connect pretensioner multiplug and secure to
seat frame.
3. Fit rear console.
4. Connect battery leads, earth lead last.
