Range Rover P38
CHASSIS AND BODY
85
REPAIR
32. Apply a continuous bead of sealer to windscreen
as shown.
33. Fit suction lifters to glass.
34. With assistance, position glass centrally, using
previously made tape markings and lower onto
supports. Seat glass to spacer blocks.
CAUTION: Do not apply heavy pressure to
the sides of the screen. Lightly press
screen from centre outwards until edges
are to required gap. Pushing screen edges into
position can bend screen and lead to cracking in
service.
35. Remove protection from fascia and bonnet.
36. Remove masking tape.
37. If fitted, connect heating element multiplugs and
earth wire.
38. Remove clips from upper screen finisher.
39. Fit clips to body studs. Position upper screen
finisher and engage to clips.
40. Fit plenum panels.
See HEATING AND
VENTILATION, Repair.
41. Fit interior mirror.
See this section.
If Cutting Wire and Handles Used
42. Remove masking from leading edge of
headlining.
43. Fit map/courtesy lamp assembly.
See
ELECTRICAL, Repair.
44. Fit sun visors.
See this section.
45. Fit ’A’ post finishers.
See this section.
CAUTION: A curing time of 6 hours is
recommended. During this time, leave the
windows open and DO NOT slam the
doors.
