Freelander Service Procedures
AUTOMATIC GEARBOX - JATCO
44-10
REPAIRS
Inhibitor switch
$% 44.15.19
Remove
1. Release inhibitor switch harness multiplug from
clip on fluid pan and disconnect multiplug.
2. Set selector lever to 'N' position.
3. Remove 2 bolts securing inhibitor switch to
gearbox and remove inhibitor switch.
Refit
1. Clean inhibitor switch and mating face on
gearbox.
2. Align the internal lugs with the mark on the
inhibitor switch.
3. Position inhibitor switch, aligning the 2 lugs with
the machined grooves in the selector lever
shaft.
4. Fit bolts securing inhibitor switch but do not
tighten at this stage.
5. Connect inhibitor switch multiplug and secure
to mounting bracket with clip.
6. Adjust inhibitor switch.
ADJUSTMENTS, Inhibitor switch - adjust.
ECU
$% 44.15.46
Remove
1. Loosen 5 screws and remove 'E' - box lid.
2. Release 2 retainers and withdraw ECU.
3. Disconnect multiplug from ECU and remove
ECU.
Refit
1. Connect multiplug to ECU.
2. Locate and secure ECU.
3. Fit 'E' - box lid and tighten screws.
M18 0672
