Freelander Service Procedures
FUEL DELIVERY SYSTEM - PETROL
REPAIRS 19-2-33
11. Remove fuel tank from cradle. Collect heat and
fire shields.
12. Remove clips from breather hose and vent
pipes.
13. Disconnect breather hose and vent pipe from
fuel tank.
Refit
1. Connect breather hose and vent pipe to tank,
secure with clips.
2. Position heat and fire shields. Fit cradle to fuel
tank.
3. With assistance, fit bolts securing fuel tank to
body and tighten to 45 Nm.
NOTE: Pass vent and breather hoses through
body while fitting tank.
4. Raise subframe, fit bolts and tighten to 190 Nm.
5. Connect breather hose to filler neck, fit and
secure clip.
6. Fit RH rear wheel arch liner.
7. Fit propeller shaft.
DRIVESHAFTS, REPAIRS, Propeller
8. Fit intermediate exhaust pipe.
- K SERIES KV6, REPAIRS, Intermediate
pipe - NAS.
9. Fit fuel pump assembly.
10. Connect battery earth lead.
