Reassemble (page 3 of 11)
- Make
- Rover
- Model
- 600 Rover 600 Repair Manual - Volumes 1 and 2 - 2nd Edition
- Section
- Repairs
Automatic gearboxReassemble · page 3 of 11
| A | Snap ring | J | Clutch drum |
| B | Clutch end plate | K | Snap ring |
| C | Clutch discs | L | Clutch end plate |
| D | Clutch plates | M | Clutch discs |
| E | Snap ring | N | Clutch plates |
| F | Spring retainer | O | Snap ring |
| G | Return spring | P | Spring retainer |
| H | Piston | Q | Return spring |
| I | 'O' rings | R | Piston |
| S | 'O' rings |
