Freelander Service Procedures
DOORS
76-1-24 REPAIRS
Plastic sheet - front door - upper - 3 door
$% 76.34.24
Remove
1. Remove front door trim casing.
2. Release and discard plastic sheet.
Refit
1. Clean door contact area with white spirit.
2. Position NEW plastic sheet to door and seal in
position, by applying hand pressure to centre
bottom of sheet first then move out from this
point in both directions applying an even
pressure to the seal, smooth out any creases.
3. Fit front door trim casing.
Plastic sheet - tail door
$% 76.34.25
Remove
1. Remove tail door trim casing.
DOORS, REPAIRS, Trim casing - tail
2. Release and discard plastic sheet.
Refit
1. Clean door contact area with white spirit.
2. Position NEW plastic sheet to door and seal in
position, by applying hand pressure to centre
bottom of sheet first then move out from this
point in both directions applying an even
pressure to the seal, smooth out any creases.
3. Fit tail door trim casing.
