Freelander Service Procedures
PANEL REPAIRS
REPAIRS 77-2-49
23. Remove rear quarter vent and seal.
Body quarter vent assembly - 3 door.
24. Remove rear damper.
25. Release vehicle harness from rear quarter and
position aside.
26. LH side: Remove tail door striker from 'E' post.
27. RH side: Remove tail door.
assembly - remove for access & refit.
28. RH side: Remove fuel filler neck.
29. RH side: Remove fuel tank.
PETROL, REPAIRS, Tank - Non NAS.
Repair
1. Remove existing panel(s), prepare panel joint
faces and install new panel(s) in accordance
with Panel Replacement Procedure. Punch or
drill holes in new panel for plug welding as
shown.
2. Arrow A is shown to highlight the fact that there
are plug welds on the other side of the inner
wheel arch as well. These are to weld the rear
longitudinal to the inner wheel arch.
Refit
1. LH side: Fit tail door striker to 'E' post.
2. RH side: Fit fuel tank.
PETROL, REPAIRS, Tank - Non NAS.
3. RH side: Fit fuel filler neck.
4. RH side: Fit tail door.
assembly - remove for access & refit.
5. Secure vehicle harness to rear quarter.
6. Fit rear damper.
7. Fit seal and rear quarter vent.
Body quarter vent assembly - 3 door.
8. Fit headlining.
9. Fit rear body side casing.
