Repair › Sun blind assembly centre console
Chassis and bodySun blind assembly centre console

SUN BLIND ASSEMBLY CENTRE CONSOLE

Service repair no - 76.82.78 Service repair no - 76.52.02

Remove Remove

  1. Open sunroof to the tilt position.
  2. Remove the trim finisher from the sunroof
  3. Disconnect battery earth lead.

surround.

  1. Release the headlining locally to access under clamping frame of the sunroof.
  2. Lever forward and upward the rear leg of 3
Remove remove – Lever forward and upward the rear leg of 3

retaining clips to release sun blind roll assembly.

Refit

  1. Ensure front leg of retaining clips are located.
  2. Push in rear leg of retaining clip.
  3. Reverse removal procedure.
  4. Release tranfer gear lever gaiter from console.
  5. Remove transfer gear lever gaiter and knob assembly.
  6. Release gear selector lever gaiter from centre console.
  7. Remove gear selector lever gaiter and knob assembly.
  8. Remove centre console rubber mat.
