Freelander Service Procedures
AUTOMATIC GEARBOX - JATCO
REPAIRS
44-19
16. Remove 2 bolts securing gearbox to engine.
17. Release HO2S multiplug from support bracket
on LH camshaft cover, disconnect multiplug.
18. Remove 4 nuts securing LH exhaust manifold
to cylinder head.
19. Remove exhaust manifold, remove and discard
gasket.
20. Position container to collect fluid spillage.
21. Disconnect 2 fluid cooler hose unions and
discard 'O' rings.
CAUTION: Always fit plugs to open
connections to prevent contamination.
22. Remove 3 bolts securing fluid cooler bracket.
23. Move fluid cooler aside.
24. Remove bolt securing CKP sensor to gearbox,
release sensor and position aside.
M44 1651
M44 1639
M44 1665
