Freelander Service Procedures
ENGINE - K SERIES KV6
REPAIRS 12-3-47
Hydramount - engine - RH
$% 12.45.12
Remove
1. Remove top arm.
ENGINE - K SERIES KV6, REPAIRS,
Arm assembly - engine mounting RH.
2. Position 3 pegs on LRT-12-169 into 3 slots in
hydramount.
3. Connect a suitable socket bar to LRT-12-169,
loosen and remove hydramount and LRT-12-
169.
Refit
1. Clean hydramount and body mating faces.
2. Position hydramount to body.
3. Position 3 pegs on LRT-12-169 into 3 slots in
hydramount.
4. Tighten hydramount to 85 Nm (63 lbf.ft).
5. Fit top arm.
ENGINE - K SERIES KV6, REPAIRS,
Arm assembly - engine mounting RH.
Engine steady - upper RH
$% 12.45.16
Remove
1. Remove 2 bolts securing RH engine steady to
top arm and body.
2. Remove engine steady from mounting
brackets.
Refit
1. Position engine steady bar, fit bolts and tighten
to 100 Nm (74 lbf.ft).
