Freelander Service Procedures
ENGINE - K SERIES KV6
12-3-24 REPAIRS
6. Using sequence shown, progressively loosen
and remove 14 bolts securing camshaft cover.
7. Remove camshaft cover, remove and discard
gasket.
Refit
1. Clean mating surfaces of camshaft cover and
carrier.
2. Position new gasket to camshaft carrier with
arrows on gasket pointing towards inlet
manifold.
3. Position camshaft cover, fit and tighten bolts
progressively in the sequence shown to 9 Nm
(7 lbf.ft).
4. Position plug top coils, fit bolts and tighten to 9
Nm (7 lbf.ft).
5. Position earth lead to RH camshaft cover, fit
bolt and tighten to 9 Nm (7 lbf.ft).
6. Secure breather hose to camshaft cover.
7. Fit inlet manifold chamber.
- K SERIES KV6, REPAIRS, Seals - inlet
manifold chamber - up to 03MY.
8. Check engine oil, top-up if necessary.
