Freelander Service Procedures
ENGINE - K SERIES KV6
REPAIRS 12-3-17
7. Depress locking collar and release breather
hose from RH inlet manifold.
8. Remove RH camshaft cover gasket.
ENGINE - K SERIES KV6, REPAIRS,
9. Release clip and disconnect coolant bleed
hose from RH inlet manifold, position hose
aside.
10. Release injector harness clips from injector
protection cover - if fitted or from bosses on fuel
rail.
11. Remove 2 bolts securing protection cover - if
fitted and RH fuel rail to RH inlet manifold,
remove cover.
12. Remove 2 bolts securing fuel rail to LH inlet
manifold.
