Electrical86M 2113 · page 1 of 4
UNDER-HOOD FUSE/RELAY BOX
- BATTERY (+)
- No.15 (80A)
- No.16 (50A)
- No.29 (15A)
- WHT/BLU
- (5W) TRUNK LIGHT
- GRN/BLK
- TRUNK LATCH SWITCH
- BLK
- LHD: G531
- RHD: G701
- WHT
- BAT IG1 IGNITION SWITCH
- BLK/YEL
- No.8 (10A) UNDER-DASH FUSE/RELAY BOX
- YEL
- A6 SAFETY INDICATOR (In the gauge assembly)
- TRUNK INDICATOR LIGHT (1.4W)
- DOOR INDICATOR LIGHT (1.4W)
- A20 GRN/BLK
- A14 GRN/RED
- R.FRONT DOOR COURTESY LIGHT
- INTEGRATED CONTROL UNIT (RHD)
- KEYLESS ENTRY and SECURITY ALARM SYSTEM
- GRN/RED
- R.FRONT DOOR SWITCH
- A11 GRN/BLU
- L.FRONT DOOR COURTESY LIGHT
- INTEGRATED CONTROL UNIT (LHD)
- KEYLESS ENTRY and SECURITY ALARM SYSTEM
- GRN/BLU
- L.FRONT DOOR SWITCH
- A12 GRN/WHT
- R.REAR DOOR COURTESY LIGHT
- KEYLESS ENTRY and SECURITY ALARM SYSTEM
- GRN/WHT
- L.REAR DOOR SWITCH
- A10 GRN/YEL
- L.REAR DOOR COURTESY LIGHT
- KEYLESS ENTRY and SECURITY ALARM SYSTEM
- GRN/YEL
- R.REAR DOOR SWITCH
- ENTRY LIGHT TIMER CIRCUIT (In the integrated control unit)
- BLK/WHT
- A28
