ElectricalComponent Location Index · page 4 of 5

F2Turn the ignition switch on.

Does the charging system light come on?
NO → To page 44

YES
Start the engine.

Does the charging system light go off?
YES Charging system light circuit is OK. Test the alternator/regulator operation.

NO
Turn the ignition switch off

Disconnect the 4-P connector from the alternator.

Turn the ignition switch on.

Does the charging system light go off?
NO Disconnect the ABS control unit as applicable. If the charging system light stays on, repair the short to earth in the WHT/BLU wire.

YES
WHT/BLU wire is OK; perform alternator/regulator test.
